Clinical Example: Staged Flexor Tendon Reconstruction

The results of repair or reconstruction of flexor tendon injuries remains frustratingly unpredictable. This series demonstrates a technique for flexor tendon and tendon sheath reconstruction.
Click on each image for a larger picture


This patient had undergone two prior procedures elsewhere for flexor tendon injuries  from a laceration in the proximal phalanx of the middle finger. There was full passive but no active flexion and fixed flexion contractures of both the proximal and distal interphalangeal joints.
Highslide
At exploration, neither A2 nor A4 pulleys could be identified. PIP and DIP capsulotomies were required to restore passive extension. Reconstruction was undertaken with a silicone tendon spacer, pulley reconstruction and preliminary flexor digitorum profundus to superficialis tendon juncture.
Highslide
The deep needle is delivering the tendons into the field. The superficial needle is maintaining an end to end orientation so that the tendon ends were approximated without angulation.
Highslide
A strip of extensor retinaculum was used as a  graft for pulley reconstruction.
Highslide
The retinacular graft was passed twice around the proximal phalanx in an effort to recreate the entire A2 pulley.
Highslide
The A4 pulley was reconstructed by bridging the graft to the remaining attachments of the A4 pulley.
Highslide
Radiographs demonstrating proper tendon spacer position and no bowstringing.
Highslide

Highslide
Second stage, three months later. The tendon spacer and the tendon-tendon juncture are exposed:
Highslide

Highslide
The FDS tendon was divided in the forearm. The proximal stump was  delivered into the palm wound, sutured to the tendon spacer and pulled out the fingertip.
Highslide
Tension was adjusted to match the cascade of the adjacent fingers.
Highslide
The distal tendon graft was brought out the fingertip, and sutured to the old FDP stump.
Highslide
That's the easy part! Now it's up to a motivated patient and a dedicated therapist to make it work.
